Led Strip Module 6W Color Temperature(CCT) 4000K RA: 97
Product Features:
1. The RA is 97, close to natural light and can be customized.
2. The CSP lamp beads can be customized, including dividual csp
beads, application extensively.
3. Low thermal resistance, long lifetime, small size, high optical
density and low energy consumption.
4. Pls preserve the base plate within the temperature 25 degree and
humidity of 60%
Technical Parameter:
| Optical Parameter | Value | Panel Parameter | Value |
| Lamp Luminous Flux(lm): | 530lm | Series Parallel Relation: | 2 parallel 7 Series |
| Color Temperature(CCT): | 4000K | Electric Current: | 0.3A |
| CRI(Ra>): | 97 | Input Voltage(V): | 18~24V |
| Power: | 6W | Thermal Conductivity: | >2.0W/M.K |
| Lamp Luminous Efficiency(lm/w): | 901Lm/W | Material: | A1 panel |
| Model Number: | LHM-2B7CD040-00740A | Brand Name: | Lohua Light Source |
| Lamp bead model: | 0909030-2828-5X-40AA | Application: | Various lighting places |
| Warranty(Years): | 2 years | Place of Origin: | Shenzhen, Guangdong, China |
| CSP size(mm): | 28*28 | Name: | 7W bulb light csp module |
| viewing angel(°): | 150° | LED Light Source: | csp lamp bead |
| Luminous intensity: | 530lm | QTY of LED: | 14pcs |
| LED Type: | 2828 | PCB Thickness: | 1.0mm |
Our Service:
1. Our own lab and factory, with a full quality control system on
production.
2. With experienced experts, sales team and after-service team.
2. We have patents in CSP, the quality is convinced.
4. Innovative research and development department and intellectual
property manage center.
Application Range:
It is widely applied in shopping malls, office buildings, hotels,
exhibition halls, conference rooms, hospitals,windows, household
etc.
Company Introduction:
Jiangsu Lohua New Material Co., LTD., founded in October 2013,
located in National High and New Technology Industrial Development
Zone of Nantong, is the first successful manufacturer of
development and production of CSP products and fluorescent ceramic
products in China. The company has always been based on the LED, a
new generation of lighting and laser display technology, providing
the overall solution of more high-quality light emitting materials
and light source for the white light. It is a national high-tech
enterprise of research, development, production, and sales of
integration with sales team in Jiangsu, Guangdong, Sichuan Province
and other places.
